Battery-less Absolute Encoder Type

Battery-less Absolute Encoder Type
Electric Actuator/High Performance Rod Type LEY□G

    ・Reduces cycle time
    　Cycle time: Reduced by 33% (0.65 s ← 0.97 s) compared with the existing
    　model∗
    　Acceleration/Deceleration: 10000 mm/s2 (334% increase compared with
    　the existing model)
    　Max. speed: 700 mm/s (Improved by 40% compared with the existing
    　model)
    　∗When LEY25GA-300 is operated from 0 to 300 mm (stroke)
    ・Battery-less absolute encoder compatible
    　Easy operation restart after recovery of the power supply
    　Maintenance labor can be reduced as the product does not require the
    　use of batteries.
  • 2D/3D CAD

    The new SMC CAD SYSTEM, CADENAS, allows you to output 2D/3D CAD data with full part numbers in various data formats. Responses to part number selection has been greatly improved with the newly developed system.

    Click here for 2D/3D CAD
    2D CAD
    Click here for 2D CAD
Safety Instructions　Electric Actuators/Precautions　Auto Switches/Precautions　Green Procurement (RoHS)
SpecificationModelStroke
(mm)		Pushing force
(N)		Speed
(mm/s)		Screw lead
(mm)
High performance
Battery-less absolute
(Step motor 24 VDC)		LEY16G30 to 300Max. 141Max. 7002.5，5，10
High performance
Battery-less absolute
(Step motor 24 VDC)		LEY25G30 to 400Max. 452Max. 7003，6，12
High performance
Battery-less absolute
(Step motor 24 VDC)		LEY40G30 to 500Max. 1058Max. 8004，8，16

Features

Reduces cycle time
